Horizontal and Vertical Belt Drive Air Handlers

When the application calls for cooling capacities or external static pressures that cannot be met with standard or high-performance direct-drive fan coil units and large central station units are a financial challenge, our horizontal belt drive air handlers are the perfect economical fit for your needs. They are great for straightforward horizontal or vertical applications with a simple design. The best applications for these units are when space requires less than 1.5” of external static pressure on the fan for ductwork and doesn’t require a custom arrangement.

Materials and Specifications

Cabinet

Heavy-gauge powder-coated steel insulated with ½” thick, three-pound density, neoprene coated fiberglass.

Coils

½” O.D. copper tube with aluminum fins (12 FPI) equipped with manual-air vent. Coils are 100% underwater pressure tested at 350 PSI with a 300 PSI working pressure.

Drain Pan

Galvanized and powder coated epoxy with a 1/8” thick closed-cell insulation and has primary and secondary drain connections.

Blower Assembly

Belt-drive, draw-through design with forward-curved and dynamically balanced blowers. Adjustable, variable-pitch drive sheave and cast-iron pulley keyed to motor shaft.

Controls and Motors

Controls & motors are factory-wired and terminated in a junction box for single-point power supply.

Filter

Two-inch thick, flat, 30% pleated efficiency filter, with spring loaded clips on each side of access door for easy maintenance without the use of tools.

UNIT TYPES
OPTIONS
Light to medium duty
Different insulations
Ranging from 800-12,000 cfm (2-3 tons)
Valves and controls
Up to 1.5” external static pressure
1 to 10 row coils
Two or four-pipe, hydronic cooling/heating, steam, direct-expansion (DX) and/or electric heat
Mixing boxes
Painted cabinet
Filter options
Horizontal and Vertical Belt Drive Air Handler configurations
Double wall
