Condenser Coils

Materials and Specifications

Our refrigerant condenser coils are built with either 3/8“, 1/2” or 5/8” O.D. tubes and multiple wall thickness options. Available for multiple refrigerant condenser applications. Shaped Condenser Coils are available in the same or opposite end designs with a multitude of circuitry available. E-coating available upon request.

Coil Company has an extensive library of OEM designs and can help with the replacement of all major OEM manufactured condenser coils, including but not limited to Carrier, Trane, McQuay, York, Heatcraft, Aerofin, American-Standard, Bohn, Colmac, Marlo, and more.

Tube O.D.
3/8"
1/2"
5/8"
Tube Thick
.014
.016
.020
Fin Thick
.006
.006
.006
Optional Tube
.022
.025
.025 | .035 | .049
Optional Fin
.0075
.0075 | .010
.0075 | .010
Fin MaterialAluminumOptional - Copper; Stainless Steel
Casing Material16 Gauge Galv. Steel Optional - 12, 14, and 18 Gauge Galv. Steel • 12, 14, and 16 Gauge 304 & 316 Stainless Steel • 14 Gauge Aluminum
Tube MaterialCopperOptional - N/A
Connection MaterialCopperN/A
Header Material CopperOptional - N/A

360° Coil View

Click & hold

Shipping

The equipment we build is specially made to meet your exact engineering requirements, but we also understand time critical projects require quick turn around. Our expedited production program allows us to offer coil shipments in as little as 10, 5, 3 and 1 working days guaranteed.

20 Business Days
Standard Shipment
10 Business Days
Added Premium
5 Business Days
Added Premium
3, 2, & 1 Business Days
Call for Pricing & Availability

IOM

We strive to provide the most stress-free and easy to complete process in the industry. With every purchase, we provide a product-specific Installation, Operation, and Maintenance manual to help guide you through a lifetime of easy operation. Should you have any questions about your product you can contact us for further assistance.

Click Here

SPECS

Want to know more? Here is the full product spec sheet that lays out product-specific details that can make a difference when it comes to your system performance and longevity. If you're not seeing exactly what you need, you can reach out to one of our highly trained sales engineers and we will take it from there!

Click Here

DRAWING

Not sure exactly what you need or how to ask for it? Fill out this easy to use step by step guide, that when completed will provide all the necessary information to our highly trained sales engineers. Not sure how to find the information needed in the drawing? Check out our how-to videos on coil measuring and drawing completion!

Click Here
Request a Quote
